Rail thickness is just 7.5 mm. Compact overtravel type of slide rail with a focus on slimness.
Both draw-out and closing have a cycle repair (ball creep repair) mechanism, reducing brake-stop (ball stop due frictional resistance) at start of operation.
Because both inner and outer members are tapped, screw processing for the rail mounting unit is not required. As well, mounting is possible using the rail hole and elongated hole.
<Recommended screws>
M2.6 Cross-recessed pan head screw for precision equipment (tap).
M2.3 Cross-recessed pan head screw for precision equipment (hole/elongated hole).
[Caution]
Mounting screw length must be within mounting unit thickneness + 1.0 mm. (Long screws will contact the ball retainer and impede rail operation or cause damage.)
General pan head screws may contact the ball retainer and impede rail operation or cause damage.
<Grease>
Nichimoly G-03031X
Specification
Custom Features
Part Number
Slide Length (mm)
Travel (mm)
Mounting Hole (mm) ± 0.3 mm
Load Capacity (N/pair)
Product Weight (kg/piece)
Quantity in Package (pieces)
A
(1)
B
(2)
(3)
C
D
(4)
70
70
85.1
-
-
35
45
-
-
35
45
59
30.00
-
100
100
121.1
35
45
70
80
30
40
60
70
59
40.00
-
125
125
147.1
55
65
95
105
45
55
95
105
59
50.00
-
150
150
173.1
70
80
120
130
55
65
120
130
59
60.00
-
Number
Part Name
Material
Remark
1
Outer member
SUS304
t: 0.8
2
Center member
SUS304
t: 0.8
3
Inner member
SUS304
t: 0.8
4
Ball retainer
SUS304
t: 0.3
5
Ball retainer
SUS304
t: 0.3
6
Ball
SWCH
3/32"
7
Ball
SWCH
3/32"
For requests concerning special sizes or specification change etc., contact our sales staff.
For special sizes, contact our sales staff.
Changes may be made without notice for improved quality, environment, and safety, without affecting function or mounting.
